INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | GG800 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case /standard container |
| Delivery Time: | Stand-alone 1 week ,the packing line 150days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Application: | Steel Pipe, Steel Tube, Plastic Pipe,aluminium | Packing Type: | Stretch Wrapping |
|---|---|---|---|
| Section Diameter Of The Pipe/bundle: | ≤1000mm | Conveyor Length: | 1000-6000mm |
| Color: | Standard Green | Wrapping Material Roll Size: | Width:≤250mm Max OD:400mm ID:55mm |
| Conveying Speed: | About 1-10m/min | Power Output: | About 1.5kw |
| Wrapping Material: | Compound Paper/anti-rust Tape/stretch Film/etc. | Warranty: | 12 Months |
| Highlight: | 10m Steel Tube Packing Machine,1.5kw Steel Tube Packing Machine |
||
1.5kw Steel Tube Packing Machine 2-10m Conveyor Length PVC Pipe Wrapping Machine
MACHINE APPLICATION:
The GG series wrapping machine is widely used for wrapping welded pipe ,steel pipe,copper tube,plastic pipe & etc.,The wrapped product is well decorated,with good rust-proff and anti damagne and so on.
MAIN PARAMETERS:
| Section diameter of the pipe/bundle | ≤1000mm |
| Package length | Not limited |
| Conveyor length | Customized |
| Conveying speed | About 1-10m/min |
| Rotating speed | 20-90r/min |
| Overlap scope | About 10%-90% |
| Wrapping material | Compound paper tape/knit tape |
| Wrapping material roll size |
Width:≤250mm Max OD:400mm ID:55mm |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
BASIC FEATURES:
◆PLC programmable controller and man-machine dialogue touchscreen.
◆Automatic fault alarming.
◆Friction structure adopted for safe, steady and strong operation.
◆Photocell sensor adopted for automatic object tracking, precise positioning, convenient and safe for operation.
◆Special tension adjust system ensures uniform tension of the packing material.
◆Protective rollers wrapped by polyurethane used to well protect the object from scratches.
◆Height of the ring center can be adjusted in accordance with the specific product.
◆Soft start and soft stop ensure safe operation.
◆Independent control cabinet, convenient for operation and maintenance.
◆The mechanical hand device can be chosen for automatic material feeding & cutting operation.
◆Two different material can be wrapped synchronously (optional).
