INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case /standard container |
| Delivery Time: | Stand-alone 1 week ,the packing line 150days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Application: | Steel Pipe, Steel Tube, Plastic Pipe,aluminium | Name: | Steel Pipe Packing Machine |
|---|---|---|---|
| Turning Speed: | 20-90r/min | Packing Type: | Stretch Wrapping |
| Pipe Diameter: | 200-800mm | Pipe Length: | Not Limited |
| Conveying Speed: | About 1-10m/min | Function: | Surface Protective Wrapping |
| After-sales Service Provided: | Online Service | Warranty: | 12 Months |
| Highlight: | 1000mm Steel Tube Packing Machine,Steel Tube Packing Machine ISO9001,GG800 Steel Pipe Packing Machine |
||
Steel Pipe Steel Tube bundle Packing Machine with material fixing and cutting by manual
Packing machine application:
The horizontal steel pipe wrapping machine is specialized for wrapping horizontal shapes of steel pipes, plastic pipes, copper tubes, profiles, bars, panels, and other horizontal objects. the wrapped package is well-protected & sealed & looks more tidy.
Packing machine installation:
The machine shall be mounted on flat & hard ground, where the ground load should be more than 1ton/m2.
Packing machine installation basic operation:
MAIN PARAMETERS:
| Tube diameter | 20mm-120mm |
| Length | 4000-6000mm |
| Bundle weight | 1-3T |
| Bundle diameter | 300-700mm |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
