INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | GS300 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden case /standard container |
| Delivery Time: | 150 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 sets/Year |
| Application: | Car Tyres, Truck Tyres | Driven Type: | Electric |
|---|---|---|---|
| Packing Type: | Stretch Wrapping Machine | Voltage: | 380V/50HZ |
| Packaging Material: | Stretch Film,paper,plastic | Ring Speed: | 20-90r/min |
| Overlap Rate: | 20%-80% Adjustable | Roller Speed: | 2-4m/min |
| Object Height: | 50-300mm | Warranty: | 12 Months |
| Highlight: | 4m/Min Tire Packing Machine,HMI Operation Tire Packing Machine,HMI Operation Tire Packaging Machine |
||
High efficient customized HMI operation rim and tire packing machine application
This tire packaging machine is widely used for tire and other coiled objects like steel coil, wire coils,pipe coil,bearings,etc.
This tire wrapping machine is with safe and easy operation
It can highly reduce high cost labor force and enhance working efficiency for modern industry.
Wrapped tire is well sealed, beautiful and looks tidier. Further more, it has waterproof, dust proof, rust proof, wear proof, anti-aging effect and etc.
High efficient customized HMI operation rim and tire packing machine parameters
| ITEMS | GS300 | GS450 | GS800 |
| Object weight | ≤500kg | ≤1000kg | ≤2000kg |
| Object height | ≤300mm | ≤450mm | ≤800mm |
| Object OD | 500-1000mm | 600-1200mm | 1000-2000mm |
| Object ID | ≥300mm | ≥400mm | ≥700mm |
| Roller speed | 2-4m,min | 2-4m,min | 2-3m,min |
| Ring speed | 30-50r,min | 30-50r,min | 20-40r,min |
| Suitable material | Stretch film, Knit tape,paper tape etc. | Stretch film, Knit tape,paper tape etc. | Stretch film, Knit tape,paper tape etc. |
| Material width | 100-150mm | 100-150mm | 150mm |
| Material OD | 150mm | 150mm | 200mm |
| Material ID | 54mm | 54mm | 54mm |
| Power output | About 3.0kw | About 4.5kw | About 6.0kw |
| Power voltage | 380V, 50HZ | 380V, 50HZ | 380V, 50HZ |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
High efficient customized HMI operation rim and tire packing machine main features:
