Place of Origin: | China |
---|---|
Brand Name: | jlpack |
Certification: | ISO9001,CE |
Model Number: | GG1200 |
Minimum Order Quantity: | 1 |
Packaging Details: | Wooden case /standard container |
Delivery Time: | Stand alone 1 week,the packing line 150 days |
Payment Terms: | T/T |
Supply Ability: | 200 sets/Year |
Application: | Wood Door,wood Panel,batten Panel Board Etc | Packing Material: | Compound Paper Tape/stretch Film/flax |
---|---|---|---|
Packing Type: | Stretch Film Wrapping | Automatic Grade: | Semi-Automatic |
Power: | 380V/50HZ | Strapping Speed: | 2.18 Sec/strap |
Turning Speed: | 20-90r/min | Warranty: | 1 Year |
After-sales Service: | Online | Color: | Standard Blue |
High Light: | Door Panel Shrink Wrap Packaging Machine,Automatic Shrink Wrap Packaging Machine,380V PE Film Wrapping Machine |
Automatic Door Panel Shrink Wrap Packaging Machine / 380V PE Film 1000mm Wrapping Machine
Application:
The horizontal wrapping machine is specially designed for long straight products package , which are easy to transport and store, and improve the appearance quality of the products
Machine installation:
1)The machine shall be mounted on flat & hard ground, where the ground load should be more than 1ton/m2.
2)Hoisting the pipe bundles onto the front conveyor line and ready to be wrapped, hoist the packed pipes away from the back convey line after package finished. The next wrapping process should begin after the back line cleared.
3)The wrapping material is tied, fixed and cut by manual.
Main premeterS:
Items | GG1200 |
Height of the product | ≤1000mm |
Pipe length | Not limited |
Conveyor length | 1000-6000mm(can be customized) |
Conveying speed | About 10m-20m/min |
Rotating speed | About 70r/min |
Conveyor height | Approx. 1000mm |
Overlap scope | About 10%-90% |
Power output | About 2.4kw |
Power voltage | 380V/ 3phase/50Hz |
Material |
Compound paper tape/knit tape/anti-rust tape/waterproof tape stretch film |
Material size |
width:≤250mm Max OD:400mm ID:55mm |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
