4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V

4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V
4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V
Basic Information
Place of Origin: China
Brand Name: jlpack
Certification: ISO9001，CE
Model Number: Customized
Minimum Order Quantity: 1
Price: USD
Packaging Details: Wooden case /standard container
Delivery Time: Stand alone 1 week,the packing line 150 days
Payment Terms: T/T
Supply Ability: 200 sets/Year
Get Best Price Contact Now
Application: Wood,window And Etc. Name: Panel Shrinking Wrapping Machine
Control System: PLC Control Material: Carbon Steel
Packing Object Size: L: 2500mm,W: 1200mm,H: 50mm Spindle Power: 3kw
Working Area: 1200*2400mm Voltage: 220V/380V/50HZ
Condition: New Warranty: 1 Year
Highlight:

9m/Min Door Shrinking Packing Machine

,

1200mm Door Shrinking Packing Machine

4-9m/min Door Shrinking Packing Machine Width 1200mm Full packaging Power Supply 380V



The alias: PLC control door heat sealing and shrinking packing machine line​





BASIC FEATURES OF THE MACHINE:

  • Adopts photo electricity for inducing the products for fix the position.
  • Two feed-in modes, auto/manual can be choosing.
  • Constant temperature heat sealing and cutting system is suitable for PE, POF and industrial standard shrink films.
  • The sealing width is adjustable for different products.
  • The front feed-in systems speed is adjustable, combines a worktable at the end of the tunnel, makes whole machine highly automatic, it runs automatically without an operator comes true.
  • Hi-speed hot air circulating shrink tunnel.
  • Sealing system: permanently heated seal bar with easy-exchangeable sealing blade without odorous, temperature controlled and detected by PLC.



TECHNICAL PARAMETERS:



SEALING PART

Control PLC
Structure Material Carbon steel
Packing object size Length: 2500mm,Width: 1200mm,Height: 50mm
Packing object Weigh ≤100kg
Working table height About 800mm
Conveyor speed

About 4-9m/min
Packaging type Full packaging
Packing material PE film
Sealing part power consumption About 4KW
Power Supply 380V
Air Supply 6~8kgf/cm2



Basic configuration:

Converter: Siemens; Transducer: Autonics

Contactor: Schneider; Switch; button: Schneider

Motor: Tunglee/YK; Cylinder: Airtac



4-9m/Min Door Shrinking Packing Machine Width 1200mm Full Packaging Power Supply 380V 0
