INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | GG700 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden case /standard container |
| Delivery Time: | Stand alone 1 week,the packing line 150 days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Application: | Steel Tube And Wood Panel , Batten Panel Etc | Packing Type: | Stretch Film Wrapping |
|---|---|---|---|
| Packaging Material: | Plastic | Height Of The Product: | ≤700mm |
| Turning Speed: | About 70r/min | Conveyor Height: | Approx. 900mm |
| Automatic Grade: | Semi-Automatic | Overlap Scope: | About 10%-90% |
| After-sales Service: | Online | Warranty: | 1 Year |
| Highlight: | 20m/min Aluminium Profile Wrapping Machine,2.4kw Aluminium Profile Wrapping Machine |
||
Industrial Profile Wrapping Machine 20m/min Conveying speed with Independent operating station
Mchine application:
The machine is specialized for wrapping horizontal steel tube,wood panels, wood door, batten board and other horizontal objects.
The wrapped package is well-protected & sealed & looks more tidy.
We offers a wide variety of opinions to meet your specific requirements.Each applications is evaluated to provide the reght solution to your needs.
MAIN PARAMETERS
| Items | GG700 |
| Height of the product | ≤700mm |
| Pipe length | Not limited |
| Conveyor length | 1000-6000mm(can be customized) |
| Conveying speed | About 8-12m/min |
| Rotating speed | About 70r/min |
| Conveyor height | Approx. 900mm |
| Overlap scope | About 10%-90% |
| Power output | About 6Kw |
| Power voltage | 380V/ 3phase/50Hz |
| Material |
Compound paper tape/knit tape/anti-rust tape/waterproof tape stretch film |
| Material size |
width:≤250mm Max OD:300mm ID:55mm |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
Main features:
Advantages of Horizontal Wrapping Machine :
• Protect the surface of the product
• Improve production efficiency
• Dust proof
• Moisture proof
• High efficiency
• Heavy duty appearance
