| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | Customized |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case /standard container |
| Delivery Time: | Stand-alone 1 week ,the packing line 150days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Application: | Plastic Coils | Driven Type: | Electric |
|---|---|---|---|
| OD: | 600-1000mm | ID: | 300-800mm |
| Packaging Material: | Stretch Film,paper Or Knit Tape | Packaging Type: | Film And Paper Wrapping |
| Voltage: | 380V/50HZ | Type: | Packing Line |
| Warranty: | 12 Months | Color: | Standard Color |
| Highlight: | 1200mm Tube Packing Machine,Automatic Wire Coil Packing Line |
||
Automatic Plastic Coil Packing Machine application:
This packing line take compound paper as main packing material,apply coil picking, auto packing,stacking & etc for plastic coils,makes the object well packed and stacked, convenient for storage and transportation.
Automatic Plastic Coil Packing Machine basic composition:
The fully auto machinery is composed of coil loading system,wrapping machine, stacking system, electrical cabinet and guardrails.
Automatic Plastic Coil Packing Machine main technical datas(for reference):
OD:600mm～1200mm
ID:300-800mm
Width:60mm～500mm
Weight:≤100KG
Wrapping material:LLDPE stretch film/compound paper
wrapping overlap: 30%～70% adjustable
Wrapping material size: film roll width 90mm, roll OD 500mm,roll ID 76mm
