INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | GD300/400 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case /standard container |
| Delivery Time: | Stand-alone 1 week ,the packing line 150days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Application: | Metal And Metallurgy Industry | Ring Speed: | Appr. 20-90r/min |
|---|---|---|---|
| Roller Speed: | 5-8m/min | Driven Type: | Electric |
| Metal ID: | ≧508MM | Voltage: | 380V/50HZ |
| Packaging Material: | Stretch Film, Paper, Knit Tape,etc | Usage: | Outer Protective Wrapping |
| Automatic Grade: | Automatic/semi-auto | Material: | Carbon Steel,metal |
| Type: | Wrapping Machine | ||
| Highlight: | 2.5/min Steel Coil Packing Machine,600mm Steel Coil Packing Machine,380V Wire Packing Machine |
||
Ring Running Steel Coil Packing Machine for Various Metal Coil Packaging 2.5/Min Roller Speed
The Packing Machine's Application
The GD type automatic steel coil wrapping machine is designed by JLPACK for automatically packing a wide range of coiled objects including steel coils, bronze coils, wire coils, pipe coils, bearings, tires & etc. The packed coil looks neat and beautiful and convenient for transportation. The machine well simplify the packing operation and free your labor forces, also improve the competitive of your products.
The machine is designed for continuous operation and is rigid and sturdy for long time usage.
The Packing Machine's Technical parameters
| ITEMS | GD300 | GD400 |
| Object width | ≤300mm | ≤400mm |
| Metal OD | ≤1200mm | ≤1500mm |
| Metal ID | ≥508mm | ≥508mm |
|
Packing material |
Compound paper tape/compound woven belt/ anti-rust tape/stretch film W:90mm ID:54mm OD:600mm |
Compound paper tape/compound woven belt/ anti-rust tape/stretch film W:90mm ID:54mm OD:600mm |
| Roller speed | About 2.5/min | About 2.5/min |
| Rotating speed | About 80r/min | About 80r/min |
| Roller loading | 2000kg | 3000kg |
| Power voltage | 380V/50Hz | 380V/50Hz |
| Synchronous wrapping system | Optional | Optional |
| Automatic mechanical hand | Optional | Optional |
Note: The datas are only for reference, the machine can be custom designed according to specific object size.
The Packing Machine's Characteristics
