INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | GD300 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case /standard container |
| Delivery Time: | Stand-alone 1 week ,the packing line 150days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Application: | Aluminium Coil, Steel Coil,copper Coil | Automation: | Automatic |
|---|---|---|---|
| Ring Speed: | Appr. 20-90r/min | Roller Speed: | 5-8m/min |
| Driven Type: | Electric | Power: | About 2.2kw |
| Packaging Material: | Stretch Film, Paper, Knit Tape,etc | Machine Name: | Aluminium Coil Wrapping Machine,aluminium Coil Packing Machine |
| Machine Weight: | About 1500kg | Machine Dimensions: | About L2200mm W1500mm H1800mm |
| Highlight: | PLC Program Aluminum Coil Wrapping Machine,90r/min Aluminum Coil Wrapping Machine,1.5kw Aluminum Coil Wrapping Machine |
||
Vertical type automatic PLC program aluminum coils packing machine 90r/Min Ring Speed
Vertical type automatic PLC program aluminum coils packing machine introduction:
The steel coil packing machine is widely used in industries of steel coils, copper coils, aluminum coils, steel wire coils, copper wire coils, cable coils and other coiled objects, the ring-shaped products of tubes, cables,pipes, wires, tires are securely wrapped through the eye for 100% surface protection. The steel coil packing machine helps a lot in labor saving and working efficiency improving.
Vertical type automatic PLC program aluminum coils packing machine application:
All kinds of ring-shaped products of all material types and sizes. Horizontal as well as vertical type are available.
Vertical type automatic PLC program aluminum coils packing machine basic features:
Vertical type automatic PLC program aluminum coils packing machine main parameters:
| ITEMS/MODEL | GD300 |
| Coil width | 10-300mm |
| Coil OD | 700-1200mm |
| Coil ID | 300-500mm |
| Packing material |
Crepe paper tape/compound knit tape/VCI paper/stretch film W:90mm ID:54mm OD:500mm |
| Roller speed | About 2.5m/min |
| Ring speed | 20-90r/min |
| Roller loading | About 1500kg |
| Power output | About 2.2kw |
| Power voltage | 380V, 3phase 4 wires |
| Machine weight | About 1500kg |
| Machine Dimensions | About L2200mm W1500mm H1800mm |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
