INDUSTRIAL AUTOMATIC PACKING SOLUTION PIONEER.
| Place of Origin: | China |
|---|---|
| Brand Name: | jlpack |
| Certification: | ISO9001，CE |
| Model Number: | GW300 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case /standard container |
| Delivery Time: | Stand-alone 1 week ,the packing line 150days |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets/Year |
| Packaging Material: | Stretch Film,paper | Driven Type: | Electric |
|---|---|---|---|
| Application: | Bearings,wire Coils,steel Coils | Voltage: | 220V/380V/50HZ |
| Type: | Wrapping Machine | Product Name: | Copper Coil Packing Machine |
| Power: | 2.0KW | Ring Speed: | 70r/min |
| Worktable Height: | 800mm | Convey Mode: | Unpowered Conveying |
| Highlight: | Horizontal Copper Coil Wrapping Machine,Electric Copper Coil Wrapping Machine,Automatic Copper Coil Packing Machine |
||
High demand Horizontal Automatic Copper Coil Wrapping Packing Machine GW300 PLC Control Electric Driven:
JIINGLIN has designed a series of horizontal coil packaging machines, which are suitable for all kinds of copper coil stretch film, composite paper, VCI paper, etc. through the eye packaging, to achieve airtight protection packaging, simplify packaging procedures, and reduce labor density. This machine can be related to The production line is connected or operated independently.
Features and advantages
1. The packaging is easy to come and go, simple to operate, and convenient to adjust.
2. A wide range of packaging films, such as paper, plastic film, etc., can use 2 different packaging films at the same time.
3. Reduce table wear and improve sealing effect , Easy to store and transport, beautiful appearance
High demand Horizontal Automatic Copper Coil Wrapping Packing Machine GW300 PLC Control Electric Driven:
| Model | GW100 | GW 2 00 | GW 3 00 | GW4 00 |
| type | horizontal | horizontal | horizontal | horizontal |
| Object width | ≤100mm | ≤200mm | ≤300mm | ≤400mm |
| Object ID | ≥150mm | ≥250mm | ≥400mm | ≥400mm |
| Object outer diameter | ≤500mm | ≤700mm | ≤1300mm | ≤2000mm |
| Object weight | ≤100kg | ≤300kg | ≤500kg | ≤1000kg |
| Ringing speed | 10-100r / min | 10-100r / min | 10-100r / min | 10-100r / min |
| Roller speed | 1-3m/min | 1-3m/min | 1-3m/min | 1-3m/min |
| Packaging material |
Stretch film/VCI film, etc. Width: 50-60mm; core inner diameter: 50mm; outer diameter: 100-200mm |
Stretch film/VCI film, etc. Width: 50-60mm; core inner diameter: 50mm; outer diameter: 100-200mm |
Stretch film/VCI film, etc. Width: 50-60mm; core inner diameter: 50mm; outer diameter: 100-200mm |
Stretch film/VCI film, etc. Width: 50-60mm; core inner diameter: 50mm; outer diameter: 100-200mm |
|
PE film/knitted tape/composite paper tape/crepe paper, etc. Width: 50-60mm, core inner diameter: 55mm, Outer diameter: 100-500mm |
PE film/knitted tape/composite paper tape/crepe paper, etc. Width: 50-60mm, core inner diameter: 55mm, outer diameter: 100-500mm |
PE film/knitted tape/composite paper tape/crepe paper, etc. Width: 50-60mm, core inner diameter: 55mm, outer diameter: 100-500mm |
PE film/knitted tape/composite paper tape/crepe paper, etc. Width: 50-60mm, core inner diameter: 55mm, outer diameter: 100-500mm |
|
| Output | About 1.5kw | About 1.5kw | About 1.5kw | About 1.5kw |
| voltage | 220V/380V,50HZ/60HZ | 220V/380V,50HZ/60HZ | 220V/380V,50HZ/60HZ | 220V/380V,50HZ/60HZ |
| Gas source | 6～8kgf/cm 2 | 6～8kgf/cm 2 | 6～8kgf/cm2 | 6～8kgf/cm2 |
| Automatic manipulator | Elective | Elective | Elective | Elective |
Note: The data is for reference only, and the machine can be customized according to the size of the specific object.
Main features of automatic copper coil packaging machine GW300 PLC controlled electric drive :
1. Horizontal structure, electric conveyor, efficient packaging.
2. A flexible winding table specially designed for bearing turning.
3. PLC and HMI realize automatic operation.
4. The tension of the packaging material and the degree of overlap are adjustable.
5.Photoelectric sensor for automatic coil positioning.
6. Different packaging materials can be selected.
7.Packaging tension can be adjusted by special crusher.
8.Independent control cabinet, easy to operate and maintain.
9, can realize automatic feeding and cutting.
10. The rotating part is equipped with a safety guardrail to ensure safe operation.
11.The roller is wrapped by polyurethane to protect the product.
12. The length of the conveyor can be customized.
